Featured Project: Big Whiskey’s
“The Brief Big Whiskey’s needed a full-scale AV solution for their Davie, FL location: a fast-paced project with a tight timeline and multiple technical requirements. The goal was to deliver an immersive customer experience while keeping the installation discreet and cohesive with the space’s design.
Our Solution We designed and installed a complete system including:
- Multizone Audio System: The system consisted of a 70V Audio System with seven (7) independent zones. It was designed with pendant, wall-mounted, and in-wall speakers to fulfill the sound requirements of each space without compromising the aesthetics of the restaurant. Seamless integration with the AVoIP system capable of outputting the audio of any of the TV inputs, including a jukebox which automatically overrode the background music when a song was requested.
- Equipment used: QSC Amp, QSC Mixer, QSC Speakers.
- AV Setup: A centralized TV system over IP of 33 independently controlled TVs across the venue. The system is able to manage 15 inputs and stream any of these on any TV throughout the venue. The web-based system allows each TV to be controlled through an iPad, Android device, or PC.
- Equipment used: AVoIP network deployed using Cisco. Transmitters, receivers, and controller by Octava.
- Network & Surveillance: Full network design and deployment, plus CCTV with remote monitoring.
- Equipment used:
- Network: Switches, routers, and access points by Ubiquiti and Netgear.
- Security System: Thirty-four (34) Hikvision Color View 8MP security cameras, two (2) Hikvision NVRs with 12TB of storage each.
- Equipment used:
Key Outcomes
- Full AV control through an intuitive interface
- Smooth audio transitions between zones and modes
- Enhanced customer experience during high-traffic events
- Improved security and streamlined daily operations
“Engineerp delivered a high-performance system that perfectly matches the energy of our venue. Everything just works — and sounds amazing.” — Operations Manager, Big Whiskey’s Davie“
