PA Sound System & Lighting Installation
Client Objective:
Deliver a high-impact audio and lighting environment suitable for events, performances, and ambient settings—while ensuring remote control capabilities and aesthetic integration with the venue.
Our Solution Design and installation of:
- PA Sound System Design and Installation: This audio system consisted of 4 Power amplified speakers of 15” Strategically mounted on the ceiling. each speaker is accompanied by an 18” subwoofer with the purpose of distributing the sound equally through the room. This is companied by a 70V Audio System for when only background music is needed.
- Equipment used: QSC Amp, Midas Mixer, RCF 15” Speakers, QSC1 L Series Subwoofers..
- Lighting and Enhancement: Six (6) Moving Head Lights, Eight (8) RGB Moving Head Laser, and Three (3) Haze Machine strategically located to enhance the lighting. This Lighting system works with a DMX communication, the controllers are connected to the internet network. So, that they can be controlled remotely using a iPad.
- Equipment used:\
- Controllers: Club 128 and Club-E 1024 DMX Controllers by Chromateq
- Lighting Fixtures: Shehds Moving Heads RGB Lasers, CHAUVET Moving Head Lights.
- Haze Machine: CHAUVET DJ Hurricane Haze 1DX.
- Equipment used:\
Key Outcomes
- Professional-grade audiovisual setup with integrated sound, lighting, and atmospheric effects.
- Enhanced user experience with remote controllability and flexible operation for different event needs (e.g., background music vs. full sound/lights setup).
